measured to be Ra0.8~1.0. "Tailstock Position 1" entered in the setting data.
M842 tailstock positioning "position 2" is set to the
"tailstock position 2" entered in the setting data.
M831 tail thrust command, specifying the tail thrust.
Table 9 Tailstock thrust control
Tailstock thrust/KN Tailstock thrust M-Code
2.0 M831
3.0 M832
4.0 M833
5.0 M834
Figure 17 Processing site 6.0 M835

7.0 M836
10.7 Use of rolling process
Although we have achieved "using turning instead of
grinding" for large shafts through turning, in order to more
reliably control the roughness, we have added a rolling process
to further enhance the roughness.

Figure 18 Center frame command setting

10.6 Center frame and tailstock control
(1) Center frame
The MAZAK E670H-4000U center frame has a clamping
range of D135-D460, while the MAZAK E670H-6000U center
frame has a clamping range of D350-D700. Parts processing Figure 19 Form of rolling tool
should be arranged reasonably according to the clamping
(1) Selection of rolling tools
range, as shown in Figure 18.
There are many types of rolling tools, as shown in Figure
N1 (Solid turning - Center frame) 19. Commonly seen are diamond and carbide rolling wheels.
G90
So how to choose for such large parts? For those with very
M286: Disconnection of cutting fluid for the center frame
long rolling times, such as rotor shafts, diamond rolling is
M292 Release the center frame prone to carbonization over time, so carbide rolling wheels are
M0 recommended.
V-1500. Center frame position V-1500
(2) Rolling parameters
M0
After some experimentation and manufacturer
M285 Connect the center frame cutting fluid recommendations, and of course, considering economic
M293 Center frame clamping
costs, we chose a domestic brand, costing around 3,000 yuan.
M0
Imported ones would cost 15,000 to 20,000 yuan. The process
(2) Tailstock parameters refer to domestic rolling cutter products. For this
See Table 9 for tailstock thrust control.
material, after multiple tests, for HB220-260 tempered steel,
M841 tailstock positioning "Position 1" is set to the
the linear speed is 50 m/min, the compression amount is 0.2~0.3
