PROCESS AND EQUIPMENTS

and tire blank outbound information via WEBSERVICE, and after the equipment arrives on site. Automatic logistics reads
automatic logistics interacts with the curing press PLC for the required tire blank specifications of the curing press and
tire blank information and related control signal interaction. delivers them to the required machine as per demand. Upon
In principle, the MES system first interacts with equipment arrival at the tire storage device, automatic logistics transmits
PLC through SCADA for control data and acquisition data, the barcode information upon arrival to the PLC of the bowl
and interacts with the host computer via WEBSERVICE as a vulcanizer. The PLC reserves 20% of its I/O points.
data supplement in standalone or offline states. The equipment
displays, controls alarms, and saves data according to the data 5 Specification parameters applicable to
downloaded from the MES system, and processes relevant data hydraulic engineering tire curing press
information for uploading. The specific data interaction format The specifications and parameters applicable to the
and interaction address will be confirmed by both parties hydraulic engineering tire curing press are shown in Table 1.

Table 1 Specification and Parameter Table of Hydraulic Engineering Tire Vulcanizer Fleet
Specifications Inner diameter of vulcanization chamber/mm Clamping force max/KN Model height /mm Bead diameter
70″ 1 815 7 500 330~750 20″~33″
88″ 2 270 9 600 500~940 20″~33″
95″ 2 410 9 600 500~980 20″~35″
105″ 2 667 13 658 600~1070 25″~36″
122″ 3 100 17 200 750~1 250 24″~36″
150″ 3 850 24 000 1 240~1 400 35″~49″
170″ 4 320 32 000 1 000~1 330 45″~51″
188″ 4 800 40 000 1 300~1 530 45″~57″
220″ 5 600 58 000 1 520~1 960 51″~63″

6 Social and economic benefits slot modules for networking, wireless communication, and
Hydraulic engineering tire vulcanization has been used other advanced automation control system functions.
on-site in multiple tire factories, and has successfully incubated (2) In terms of application costs: Due to the centralized
a full series of inch sizes, including 68, 72, 88, 95, 105, 122, thermal system, there is greater savings in thermal pipelines
150, 170, 188, and 220. It has received unanimous praise from and thermal losses. Each tire can only save and reduce
tire manufacturers and users, and customers are currently thermal power by more than 3%, while the investment cost
placing additional orders. can be saved by more than 30%. In summary, the successful
(1) Advanced functionality: The mobile frame adopts development of the vulcanization cluster production line holds
servo motors for precise positioning, and utilizes PLC empty broad market prospects.

Vol.52，2026 ·25·
