INTELLIGENT AND DIGITAL APPLICATIONS

Development and design of virtual simulation system for rubber mixing process

1
Wu Xiaofan , Sun Mingdian , Wang Shiwei , Wang Tao 1*
1
2
(1. Shenyang University of Chemical Technology, Shenyang 110142, Liaoning, China;
2. Tianjin Shiwei Technology Co. LTD., Tianjin 300000, China)
Abstract: Based on rubber processing research, this article utilizes computer technologies such as Unity3D
and 3Dmax to construct a three-dimensional scene and process flow of the rubber mixing workshop. It designs
and develops a virtual simulation system for the rubber mixing process. This system features perspective
observation of the internal process, supports free movement for visitors, has strong interactive simulation
capabilities, and professional page design. Taking the F270 type internal mixer as an example, the system
demonstrates the structure and working principle of the main equipment and achieves interactive operation,
fully reflecting the advantages and characteristics of combining rubber mixing technology with a virtual
simulation platform.
Key words: rubber mixing process; virtual simulation; Unity3D; interactive simulation
Classification number: TQ330.493 Article number: 1009-797X(2026)01-0015-04
Document code: B DOI:10.13520/j.cnki.rpte.2026.01.005

0 Introduction technologies such as Unity3D and 3DMAX to mimic real
The rubber product industry is one of the important basic factory production scenarios. Key operational processes are
industries in the national society. The development of the simulated with real-time interaction, providing users with an
industry reflects the overall development level of the national immersive experience while allowing for free exploration and
economy and modern high-tech fields. Vigorously promoting interaction . The system possesses unique advantages such as
informationization and automation technology and realizing the interactivity, learnability, ease of operation, and fun, making
standardization and intelligence of rubber production are also it suitable for training and teaching purposes. For personnel in
trends in the industry's development. There are various types the rubber products industry and related enterprises, it allows
of rubber products, and their production processes are basically for a full integration of theory and practice, enabling them to
the same. Among them, rubber mixing is an extremely master practical skills and achieve self-learning outcomes.
important process . Raw rubber undergoes multiple stages of
plasticizing through various equipment such as open mills, 1 Design process of virtual simulation
internal mixers, upper and lower auxiliary systems, rubber system for rubber mixing process
sheet coolers, and rubber cutting machines . After batching, This system takes the rubber mixing process as the
mixing, and sheet pressing, it obtains mixed rubber compound research object, uses the F270 type internal mixer as the
that meets performance requirements, preparing for subsequent physical model, and takes tire manufacturing enterprises
molding processes. as the prototype to carry out high-fidelity design of scripts,
Due to issues such as multiple mixing unit equipment,
large footprint, complex operational processes, and difficulties Biography: Wu Xiaofan (1998-), female, holds a master's degree and is
primarily engaged in virtual simulation teaching of polymer materials.
in manual operation in the real-world rubber mixing process, Funded Project: Key Cultivation Project for Teaching Achievements of
a virtual simulation system is constructed using computer Education and Teaching Cultivation Engineering at Shenyang University of
Chemical Technology

Vol.52，2026 ·15·
