             损伤。综上所述，通过对输出轴的结构和材料进行优                           [4]   杨成云，林腾蛟，李润方，等 . 中心传动齿轮箱体有限元分析
                                                                   及结构优化设计 [J]. 重型机械，2001(2):42-45.
             化，降低了最大应力并提升了安全系数。优化后的方
                                                               [5]   王鹏，张 柱银，夏建生， 等 . 基于 ANSYS Workbench 的高
             案不仅可行，而且显著提高输出轴的疲劳寿命和可靠
                                                                   速轴瞬态动力学分析 [J]. 盐城工学院学报 ( 自然科学版 )，
             性。这一研究成果为今后工作提供了有益的参考和借                               2017,30(03):22-25+34.
             鉴。                                                [6]   徐彩玲 . 渐开线直齿齿轮轴楔横轧三维有限元模拟分析 [J]. 热
                                                                   加工工艺，2013,42(05):91-93+96.
                                                               [7]   余焕伟，陈仙凤，任绪凯，等 . 某 40Cr 汽车稳定杆球头销断
             参考文献 ：                                                裂失效分析 [J]. 汽车实用技术，2024,49(09):141-145.
             [1]   韩彦林 . 阴阳转子型双螺杆挤出机挤出成型机理及设备研究                [8]   吴宗泽 .  机械设计实用手册 ( 第三版 )[M].  北京 : 化学工业出
                 [D]. 沈阳化工大学，2022.                                 版社，2010.
             [2]   李世通 . 双螺杆挤出机传动系统分析及高扭矩设计探讨 [J]. 北           [9]   张志宏，刘忠明，王征兵，等 . 起重机减速器疲劳强度计算方
                 工机械 , 1999(6):23-28.                              法分析 [J]. 机械传动，2018,42(11):72-75.
             [3]   Kish J. Comanche Drive System. Rotary  Wing Propulsion   [10]  吕志强 . 航空发动机轮盘低周疲劳寿命预测方法研究 [D]. 电
                 Specialists Meeting: Proceedings[J]. American Helicopter   子科技大学，2016.
                 Soeiety, 1993.



                         Strength analysis and optimization of output shaft for
                            co-rotating twin-screw extruder transmission box


                                          Zhang Xiao, Ma Yongshou, Liang Xiaogang
                   (Tianhua Institute of Chemical Machinery & Automation Co. LTD., Lanzhou 730060, Gansu, China)
                 Abstract: The transmission system of a twin-screw extruder converts high-speed, low torque power
             into low-speed, high torque output through a reduction device, thereby driving the screw to transport the
             material forward. This article takes the output shaft of the SHJ-600 high torque co rotating twin-screw extruder
             transmission box as the research object, and uses finite element analysis method to conduct static and fatigue
             analysis on it. Through analysis, key parameters such as deformation of the output shaft, equivalent stress-
             strain cloud map, life prediction, and safety factor were obtained. Research has found that the main cause of
             output shaft fracture is fatigue failure. Based on this, the structure and material of the output shaft have been
             optimized and improved. The results showed that the maximum stress of the optimized output shaft decreased
             to 38.8% of the original, and the safety factor was significantly improved, verifying the feasibility and reliability
             of the optimization scheme and providing reference ideas for the design and optimization of high-strength
             shafts in the future.
                 Key words: finite element; output shaft; static analysis; fatigue strength analysis
